High And Medium Voltage Gallium Nitride Devices

- Advertisement -

The two new generations of high and medium-voltage devices utilise Gallium Nitride, revolutionising digitalization and decarbonization across industries.

GaN

Infineon Technologies AG has announced two new generations of high-voltage (HV) and medium-voltage (MV) CoolGaN devices. These advancements now allow customers to utilise Gallium Nitride (GaN) across voltage classes ranging from 40 V to 700 V, expanding its application reach in driving digitalization and decarbonization.

The press release states that the 650 V G5 family caters to applications in consumer electronics, data centres, industrial sectors, and solar energy. Representing the next evolutionary step in GIT-based high voltage products from Infineon, these offerings exhibit cutting-edge technology. The second new family, manufactured using the 8-inch process, also comprises medium voltage G3 devices. These include CoolGaN Transistor voltage classes of 60 V, 80 V, 100 V, and 120 V, along with 40 V bidirectional switch (BDS) devices. Targeted primarily at motor drives, telecommunications, data centres, solar energy, and consumer electronics, the medium voltage G3 products meet diverse application needs.

- Advertisement -

Some of the key features of the GaN transistors include:

  • 100 V – 700 V GaN transistors
  • Enhancement mode (e-mode)
  • 4 A to 150 A selection range
  • Integrated power stages
  • Broad package selection
  • Ultrafast switching-speed
  • No reverse-recovery charge
  • Capable of reverse conduction
  • Low gate and output charge
  • Superior FOMs

“Today’s announcement builds nicely on our acquisition of GaN Systems last year and brings to market a whole new level of efficiency and performance for our customers,” said Adam White, Division President of Power & Sensor Systems at Infineon. “The new generations of our Infineon CoolGaN family in high and medium voltage demonstrate our product advantages. They are manufactured in 8 inches, demonstrating the fast scalability of GaN to larger wafer diameters. I am excited to see all the disruptive applications our customers unleash with these new generations of GaN.”
