EDA Tool With Enhanced Support For Multi-Board Projects

84


Enables fast and accurate development of high-speed differential pair signals with automatic skew correction and target length matching

Labcenter Electronics Ltd., the Electronic Design Automation (EDA) company, has released the Proteus v8.12, which completes support for differential pair routing with pass-through components.

The EDA tool enables fast and accurate development of high-speed differential pair signals with automatic skew correction, target length matching and dedicated reporting features. Version 8.12 also supports the multi-board design, where a single schematic encompasses the design logic for multiple PCBs.

Configuration
Differential Pairs

Proteus includes support for multiple rigid boards per project, each of which can have different layer stackups and design rules. Documentation outputs, such as the Bill of Materials and production outputs, such as Gerber X2, are all board-aware. The design explorer module enables a global overview and easy navigation.

Routing Mode

“Proteus v8.12 is another important release in our PCB Design technology roadmap,” said Iain Cliffe, Executive Director at Labcenter Electronics. “It completes the first phase of work on high-speed design support and also introduces dedicated features to support multi-board project design.”
