Validation of 10 Gbps End-to-End (E2E) IP data performance using R&S CMX500 5G radio communication tester platform
Rohde & Schwarz has announced the next breakthrough in 5G data performance. With the support of Qualcomm Technologies, Inc., Rohde & Schwarz has validated 10 Gbps end-to-end (E2E) IP data performance using its R&S CMX500 5G radio communication tester platform. The setup was powered by Snapdragon X65 5G Modem-RF System, the world’s first 3GPP Release 16 modem-RF system with Qualcomm QTM545 mmWave Antenna Module.
In the simulation, two cell groups were simultaneously connected, one using spectrum in the frequency range 1 (FR1) and the other in the frequency range 2 (FR2; mmWave). The FR1 carrier spans over a full 100 MHz bandwidth using an antenna configuration of MIMO 4×4 and 256QAM modulation. Eight additional component carriers are combined in FR2, using MIMO 2×2 and 256QAM modulation.
The demonstration covered several test cases that verified high data throughput in downlink over IP layer, using different configuration modes of the 5G protocol stack’s lower layers such as Radio Link Control (RLC) in Unacknowledged Mode (UM) and Acknowledged Mode (AM). These configuration modes made it possible to push real IP data over the wireless communication link, making this the first time that real IP end-2-end data was used in a performance of this kind. Previously, throughput had simply been verified on the modem’s lower layer 5G protocol stack. This opens up a new era of 5G data performance, which eventually will enable eMBB use cases like 4K and 8K video streaming or augmented reality applications.
Christoph Pointner, Senior Vice President Mobile Radio Testers at Rohde & Schwarz, said, “Qualcomm Technologies’ leadership position in advanced modem architecture helped us to validate the capabilities of our hardware. By testing the R&S CMX500 against real modem implementation, we accomplished a new milestone in IP data throughput. 10 Gbps pave the way for much-discussed 5G features, which end users are already waiting for.”
