Dual Antenna GPS/GNSS Module For Accurate Positioning

- Advertisement -

The compact module is an ideal navigation and control solution for robotics, UAVs and autonomous applications

With dual antenna capabilities, the mosaic-H heading receiver surface-mount module delivers reliable heading & pitch or heading & roll information on top of centimetre-level positioning.

- Advertisement -

mosaic-HTM delivers orientation angles immediately from the start, helping initialise inertial systems which otherwise would require movement before they can measure 3D orientation. INS initialisation with GNSS from power-up allows machine trajectory path optimisation and fully informed navigation of robotic systems immediately from mission start.

mosaic-H is the new addition to Septentrio’s existing mosaic module family, which already includes high-performance RTK and timing modules as well as modules with integrated GNSS corrections.

“The mosaic GNSS receivers have set a new performance standard among high precision GNSS modules. Second antenna input is added into the single form factor of mosaic,” said Francois Freulon, Head of Product Management at Septentrio. “Thanks to its ultra-small dimensions and low power consumption, mosaic-H is the ideal navigation and control solution for robotics, UAVs and autonomous applications which require ultra-robust and secure positioning and heading.”

mosaic-H is the newest addition to Septentrio’s existing mosaic module family, which already includes high-performance RTK and timing modules as well as modules with integrated GNSS corrections.

The mosaic-H receiver will be available for integrator testing and customer evaluation by the end of December 2020. The full product production is expected by spring 2021.
