Software For Optical Communication

- Advertisement -

Check out the various software like Viavi FiberChekPRO, OptiSystem, RSoft OptSim, cableScout and KITS for Optical Communication.

Viavi FiberChekPRO

Visit the website

Full version: Free

- Advertisement -

FiberChekPRO is an automated fibre inspection and analysis software for an optical network. The performance check ensures preservation of fibre-optic interconnects. The software performs acquisition of the fibre image and finds defects along with their location relative to the fibre core. When used with digital microscopes, it identifies and characterises the defects and contamination, and provides a pass or fail result according to the pre-configured failure criteria setting. Also, it allows users to import saved data from Viavi devices (like SmartClass Fiber), archive data, generate reports and obtain optical power measurements. Consolidated reporting option enables comparison between multiple tests performed on different fibres.

OptiSystem

Visit the website

Full version: Paid; free trial

OptiSystem enables planning, testing and hierarchical simulation of optical network designs, single-mode/multi-mode transmission, etc in both time and frequency domains. Its elaborate design suite provides global insights into system performance and aids design tolerance specifications. The cost analysis table of the system can be designed according to the system, layout or component, and exported to other applications. It is compatible with Windows 7/8/10 (64-bit). The latest version 16.0 comes with many enhancements and fixes such as the addition of an approximate number of guided modes and Fiber Bragg Grating (FBG) sensor to perform temperature, stress, strain sensing and so on.

RSoft OptSim

Visit the website

Full version: Paid; free trial

RSoft OptSim is a software tool for computer-aided design (CAD) and simulation of optical communication systems at the signal propagation level. Its easy-to-use graphical user interface (GUI) and lab-like measurement instruments provide usability and accuracy. It implements both time domain split step and frequency domain split step for simulation of an optical link architecture. Applications include coherent optical communication systems, analogue and digital cable TVs, advanced modulation formats and optical interconnects.

cableScout

Visit the website

Full version: Paid; free trial

The cable management system cableScout is a cost-effective, easy-to-use software in a wide range of industry sectors for documentation and administration of fibre, fibre-to-the-home (FTTH) and copper networks. It allows data collection and transparent representation of complex optical fibre, copper, broadband and fibre-to-the-X (FTTx) structures. The entire information from throughout the network is stored in a central database providing error-free and integrated administration of all optical and electrical last-mile technologies. Other functions include plausibility checks, route finding, capacity and utilisation statistics, work orders, different computation methods in the passive optical network (PON) and coax sector, as well as numerous planning options. It is compatible with Windows, iOS and Android.

KITS software

Visit the website

Full version: Free

KITS is an Excel-based data acquisition, analysis and reporting software for fibre-optic power, attenuation and integrated optical return loss. It works with all KI2000 and KI7000 series power meters, loss test sets and two-way +ORL testers to achieve flexible cable acceptance testing. Full-feature capability includes real-time interactive data acquisition, data logging, a real-time meter display, file import/export, importing data from instrument memory and manual information input. The latest version 4.16 comes with additional features such as an updated user interface from old command bars to office ribbons and an overview of available functions through demo mode.
