Anti-Surge Thick Film Resistor With Enhanced Power Rating of 0.5W

- Advertisement -

The RCS0805 e3 from Vishay Intertechnology offers good pulse load performance and ESD surge characteristics.

The resistor is suitable for automotive, industrial, telecommunications, and medical applications.

Vishay Intertechnology has enhanced its Vishay Draloric RCS0805 e3 anti-surge thick film resistor by increasing its power rating to 0.5W. The resistor comes in a 0805 case size, the company claims that it can replace multiple standard parallel resistors in smaller case sizes, allowing for board space savings in automotive, industrial, telecommunications, and medical applications. The RCS0805 e3 offers superior pulse load performance and ESD surge characteristics compared to standard chip resistors, making it suitable for applications subject to high and repetitive surge pulses. This resistor is suitable for automotive, industrial, telecommunications, and medical applications.

- Advertisement -

The company claims that compared to standard chip resistors, the RCS0805 e3 offers superior pulse load performance and ESD surge characteristics. It is AEC-Q200 qualified and features a resistance range from 1 Ω to 10 MΩ, including a 0 Ω jumper option. The resistor has tolerances of ± 0.5%, ± 1%, and ± 5%, with TCR values of ± 100 ppm/K and ± 200 ppm/K. It operates at a voltage of 150 V and has an operating temperature range of -55 °C to +155 °C. The key features and benefits of the Vishay Draloric RCS0805 e3 anti-surge thick film resistor includes its 0805 case size, resistance range, resistance tolerance, TCR values, rated dissipation P70 of 0.5 W, the operating voltage of 150 V, and operating temperature range of -55 °C to +155 °C.

According to the company, it is RoHS-compliant and halogen-free, making it compatible with various assembly and soldering processes. New Yorker Electronics, as a franchised distributor, offers samples of the enhanced RCS0805 e3 with lead times of 12 weeks. They also supply other Vishay Draloric products, including MELF resistors, ceramic capacitor products, thin film flat chip resistors, leaded film and wire-wound resistors, and large ceramic power capacitors.
