Every system has an analog part that can fail. Before testing hardware, engineers run a free simulator. That simulator is LTspice, and it is still in use.
LTspice is an Electronic Design Automation (EDA) design tool for circuit design and simulation. It is an Analog Devices’ SPICE-based simulator and is totally free for personal and commercial projects. SPICE acts as the core simulation engine in LTspice. LTspice is built on SPICE, meaning it uses the very same mathematical models and methods to analyze electronic circuits. There are various versions and variants of SPICE over the years like PSPICE, HSPICE, etc. LTspice stands out from other SPICE versions because it is completely free and is considered best for fast, practical analog and power electronics simulation.
LTspice enables the engineer or student to design and test a circuit on the computer using the proven SPICE simulation engine. We are able to run LTspice on Windows and Mac. Engineers can use it to understand how a circuit will behave before we build any hardware. Even when we work on digital systems like controllers, sensors, or multimedia boards, there is always an analog section somewhere, and that is why LTspice simulation matters in real design work. “LTspice is a practical tool that gives early insight into circuit behaviour. For beginners, it also works as a learning aid by letting you visualise the response before building the hardware,” said one user.
Here are the core analysis types we get inside LTspice:
- Transient analysis shows how the circuit behaves over time, such as during power-up or switching behaviour.
- AC analysis shows gain and phase versus frequency and can also sweep a component value.
- DC sweep steps a voltage or parameter to check safe operating limits.
- Noise analysis shows noise versus frequency so we can design filters and re-test.
- Monte Carlo analysis runs many simulations with tolerances to check the worst-case and see if we stay in spec.
We also get fast calculation, good convergence, no limit on node count, a built-in schematic editor, and an integrated waveform viewer. LTspice ships with a large device library, especially for Analog Devices regulators and amplifiers, along with standard analog components.
When a design goes beyond basic circuits, the results from LTspice such as voltage margins and switching behaviour are passed into some PCB tools. Those tools can use that information to make better layout and routing decisions, so the board design stage becomes faster and safer. Still, even then, LTspice remains at the center because we are getting robust simulation capability without a licence cost.
We put parts such as transistors, diodes, resistors, and ICs directly onto the schematic in LTspice, execute the simulation, and view the results in one and the same window. With options such as parametric sweep, Monte Carlo, and thermal checks, we are able to stress-test the same design under numerous conditions. A parametric sweep changes one part value step by step to see how the output shifts. Monte Carlo runs many random variations of the same circuit to check if the design still works when real-world tolerances come into play. Thermal checks help us see how heat changes the behaviour of parts so we can confirm that the circuit will stay within limits in real use.
What’s new?
LTspice 24 is not a small patch. It is a major upgrade. The most recent build (24.1.10, dated September 4, 2025) simulates faster than previous versions. A notable addition is the frequency-response analysis (FRA) device that comes built-in. With FRA, we can now simulate frequency-response analysis right on non-linear circuits, which is particularly handy when we are designing loop stability and regulation speed in switch-mode DC-DC converters.
The update provides a number of improvements and additions. Some of them are mentioned below:
- Improved simulation performance: The program now runs simulations faster and is better at solving tricky circuits that earlier versions sometimes struggled with.
- Support for directory hierarchy: You can now organize your files in folders and LTspice will still find your components and schematics.
- Enhanced netlist syntax checking: The new version checks your circuit description more carefully for mistakes or errors.
- Easy stepping of models and subcircuits: You can now use text strings to define certain values in models or subcircuits, and then run parameter sweeps easily.
- Remember waveform compression settings: When you view simulation results, you can zoom or compress them the way you like, and LTspice will remember your settings the next time you open it.
- Always interpret “3k4” as 3.4 k: Until now, the “3k4” syntax was ambiguous − did it mean 3.4k or 34k? Now LTspice will always recognize it as 3.4 kilo-ohms.
- Updated help documentation: The help files and guides within LTspice are more complete now and easier to read, thus making it easier to learn and troubleshoot.
- Bug fixes: Several bugs and issues were encountered and corrected in the previous versions, making the program more reliable.
“Earlier builds effectively used only two threads for typical switching circuits. LTspice 24 now uses around 7–8 threads, giving roughly a 2×–3× real-world speedup. On laptops with few cores, users may reduce the thread count to avoid high fan noise,” one of the users added.
Limitations of LTspice
LTspice also has some practical constraints. We have listed a few of them below:
- Steep learning curve for first-time users: LTspice can feel difficult at first. There are many commands, settings, and simulation options. Beginners may need time to understand how to set up and run simulations properly.
- Interface is functional but outdated: The program works well, but the look and feel are old-fashioned. It’s not as modern or visually polished as some newer circuit design software.
- Limited capability for pure digital simulation: LTspice is mainly for analog circuits. It can simulate some digital logic, but large digital circuits like microcontrollers or FPGA logic are not well supported.
- The integration with other EDA applications is not always smooth: LTspice doesn’t always connect easily with other design software. Importing or exporting designs to other EDA applications can be tricky.
- May feel too complex for a very simple circuit: For basic circuits (like a single LED or resistor setup), LTspice can feel overkill. Simpler tools may be easier for very small projects.
Despite these restrictions, engineers still employ LTspice as it provides correct SPICE outputs with no licence fee, which is useful for learning as well as actual design projects.
Key reasons engineers use LTspice
Engineers rely on LTspice because it gives them a fast and safe way to study circuit behaviour before touching hardware.Some reasons are given below:
- Low cost and accessible: No cost to download or utilize, beneficial to individuals, startups, or small groups
- Rapid design iteration: Design modifications and many simulations can be experimented with in seconds without constructing hardware
- Safe and low-risk testing: Issues can be found without damaging real boards or costly components
- Accurate analysis and verification: Engineers can see real circuit behavior, verify function, and check how parts affect output
- Strong analysis tools: Supports waveform plotting, RMS calculations, and Fourier analysis, useful even for signals like vibration data
- Efficient workflow: Includes schematic capture with a built-in component library and support for adding third-party models
Because of these points, LTspice remains the first tool many engineers open before building real circuits.
LTspice Licensing and Cost
If we want to simulate circuits without paying for software, LTspice is one of the easiest options to pick. We don’t have to pay for a license, renew a subscription, or even register something. “The biggest advantage of LTspice is that it is free to use for circuit design and analysis. It can act as an alternative to licensed tools like Cadence, ADS, or Altium for studying circuit behaviour,” said one user.
Cost
- Free for all users — no purchase required
- No hidden or recurring fees
License
- We are allowed to use it for commercial work without charge
- We can use, modify, and redistribute the software
- Redistribution must follow a few rules:
- We must not misrepresent where the software came from
- If we modify it, we must clearly mark it as modified
- We must include the original copyright and license
The complete license text also includes terms on liability and legal responsibilities. If we intend to modify or redistribute LTspice, we should read the license carefully first.
LTspice is a convenient method by which we can understand or test a circuit before actually building it. It’s free, fast, and works well for analog and power electronics. We can run simulations, check how parts behave with changes, test for tolerances using Monte Carlo, and even see how heat affects the circuit. The interface may look old and it’s not perfect for big digital systems, but it still gives us accurate results without spending money. With the latest updates, simulations are faster, easier, and more reliable, so we can focus on designing our circuits with confidence before touching any hardware.
