DC/DC Converters For Space-Limited Applications

- Advertisement -

The DC/DC converters are designed for tight spaces, offering efficiency and performance in industrial and technological environments.

DC/DC Converters

RECOM has introduced a new line of isolated through-hole DC/DC converters designed for space-limited product configurations, available in 10W, 20W, and 30W models. These components, housed in compact 1” x 1” industry-standard packages and only 0.4” high, offer cost-effectiveness, broad input ranges, and high efficiency for dependable performance in high ambient temperatures.

The target users of isolated through-hole DC/DC converters span multiple industries where compact, efficient, and reliable power solutions are crucial. Key user groups include electronics designers and engineers working on space-constrained electronics, automotive industry professionals needing durable power supplies for varying temperatures, firms in industrial automation, telecommunications companies, and aerospace and defence entities.

- Advertisement -

The REC30K series, rated at 30W, mirrors these input and output options but includes an additional input range of 36V to 75V with a 2:1 ratio and enhanced efficiency. The REC10K models can operate in ambient temperatures ranging from -40°C to 100°C with derating, whereas the REC20K and REC30K series can handle up to 105°C.

These units maintain tight control over line and load regulation, exhibit low ripple and noise, and allow for a +/-10% adjustment in output voltage on single-output models. Comprehensive protection against input Undervoltage, output overcurrent, overvoltage, and short circuits is standard. An on/off control feature minimises the current draw when the DC/DC converters are not in use, making them suitable for energy-efficient applications.

Isolation meets the ‘functional’ grade defined by IEC/EN/UL62368-1 standards, with 1600VDC/1 min for REC10K models and 2kVDC/1 min for REC20K and REC30K models. External filters, as recommended in the datasheets, are necessary to achieve ‘Class A and B’ EMI standards.

Matthew Dauterive, MSc. RECOM’s DC/DC product manager comments, “Our advanced design and packaging techniques in these new DC/DCs result in a great combination of power density, performance, and price, ideal for space—and cost-sensitive applications where quality cannot be compromised.”

For more information, click here.
